SANA2 Fiber Endface Interferometer

SANA; 2 is a new manual focusing automatic interpreter developed by Dimension Technology This device inherits years of experience in participants from Dimension Technology and innovatively realized functions such as automatic adjustment of APC angle, automatic measurement, and automatic display of results based on SANA

SANA; Using a brand new software design, the measurement accuracy has been further improved and the measurement speed has been increased to 0.5 seconds

SANA; 2. Adopting a brand new fixture platform structure and fixture structure design, the seismic resistance of the equipment has been improved, and the service life and measurement stability of the fixture has been greatly improved

Accurate and fast fully automatic measurement
0~12 °  APC; Fully automatic angle adjustment
Unique Chinese and English operation interface, fast conversion
Automatically generated data reports and 3D graph reports
Automatic centering function of fixtures

Main applications

Fully automatic measurement

SANA; 2  Unique fixture platform design equipped with fixture locks; Tight sensing structure, capable of automatically observing the locking of the current fixture; Condition, automatically measured by the software every time the fixture is locked; Greatly improves the efficiency of detection

SANA; 2  The front of the fixture platform is also equipped with a measuring device; Quick key, press lightly to complete the measurement task

SANA2; The intermediary fixture attachments a brand new design and is installed in the dry position; After the device is installed, there is no need to make any hardware adjustments, just use the software; Click the “Image Center” button on the interface, and the software will automatically; Guide to complete the positioning of the cursor

SANA; 2  The fixture platform design can be freely implemented; Width from 0 to 12 °; Wide angle adjustment range to meet customer requirements for connector special angles; Testing requirements for; The fixture platform can be provided; The adjustment accuracy is 0.003 °, and each measurement software provides angle compensation function, making it possible to; The measurement of angles achieved higher accuracy

SANA2; The interface measurement software has a unique Chinese and English operation interface, with fast functions such as free conversion, making the operation interface intuitive and clear; It realistic; 3D; Restoring ability, allowing users to visually judge the condition of the fiber end face and generate; Assist engineers in making improvements to the grinding process through surface roughness maps and vertex profile maps Data reports and each test; The quantity chart report can be randomly and automatically generated&Nbsp; Consensus for data; Analyze and save
